HRN Main Rod Seal | Factory Wholesale
HRN Main Oil Seal Rod Seals overview
Upgrade your hydraulic systems with premium HRN Main Oil Seals. Engineered for superior leak prevention, high temperature resistance, and extended service life in demanding industrial applications. Contact our B2B experts for bulk wholesale pricing and custom OEM/ODM services.
Key parameters
| Parameter | Value |
|---|---|
| Material | Composite material |
| Performance | Working pressure: ≤40 MPa; Working temperature: -35–120°C (130°C for short periods); Speed: ≤1.2 m/s. |
Available sizes
65 size(s) recorded for this profile. Dimensions in millimetres unless noted otherwise.
| Inner Diameter (ID) | Outer Diameter (OD) | Height (h) | Groove Width (L) |
|---|---|---|---|
| 45 | 55 | 6 | 7 |
| 50 | 60 | 6 | 7 |
| 50 | 63 | 10 | 11 |
| 50 | 65 | 9 | 10 |
| 55 | 65 | 6 | 7 |
| 55 | 65 | 8 | 9 |
| 55 | 68 | 10 | 11 |
| 55 | 70 | 9 | 10 |
| 60 | 70 | 6 | 7 |
| 60 | 70 | 8 | 9 |
| 60 | 73 | 10 | 11 |
| 60 | 75 | 9 | 10 |
| 65 | 75 | 6 | 7 |
| 65 | 75 | 8 | 9 |
| 65 | 78 | 10 | 11 |
| 65 | 80 | 9 | 10 |
| 70 | 80 | 6 | 7 |
| 70 | 83 | 10 | 11 |
| 70 | 85 | 9 | 10 |
| 75 | 85 | 6 | 7 |
| 75 | 88 | 10 | 11 |
| 75 | 90 | 9 | 10 |
| 75 | 90 | 10 | 11 |
| 80 | 90 | 6 | 7 |
| 80 | 93 | 10 | 11 |
| 80 | 95 | 9 | 10 |
| 80 | 95 | 10 | 11 |
| 85 | 100 | 9 | 10 |
| 85 | 100 | 10 | 11 |
| 85 | 105 | 12 | 13 |
| 90 | 105 | 9 | 10 |
| 90 | 105 | 10 | 11 |
| 90 | 110 | 12 | 13 |
| 95 | 110 | 9 | 10 |
| 95 | 110 | 10 | 11 |
| 95 | 115 | 12 | 13 |
| 100 | 115 | 9 | 10 |
| 100 | 115 | 10 | 11 |
| 100 | 120 | 12 | 13 |
| 100 | 120 | 15 | 16 |
| 105 | 120 | 9 | 10 |
| 105 | 120 | 10 | 11 |
| 105 | 125 | 12 | 13 |
| 105 | 125 | 15 | 16 |
| 110 | 125 | 9 | 10 |
| 110 | 125 | 10 | 11 |
| 110 | 130 | 10 | 11 |
| 110 | 130 | 12 | 13 |
| 110 | 130 | 15 | 16 |
| 115 | 130 | 9 | 10 |
| 115 | 130 | 10 | 11 |
| 115 | 135 | 12 | 13 |
| 115 | 135 | 16 | 17 |
| 120 | 135 | 9 | 10 |
| 120 | 140 | 10 | 11 |
| 120 | 140 | 12 | 13 |
| 120 | 140 | 15 | 16 |
| 125 | 140 | 9 | 10 |
| 125 | 145 | 12 | 13 |
| 130 | 145 | 9 | 10 |
| 130 | 145 | 10 | 11 |
| 130 | 150 | 12 | 13 |
| 130 | 150 | 16 | 17 |
| 140 | 160 | 12 | 13 |
| 150 | 170 | 12 | 13 |
Applications
- Hydraulic cylinders on excavators, loaders, cranes and other mobile machinery
- Industrial cylinders, presses and hydraulic power units
- Replacement seal programmes for maintenance and repair workshops
Request a quote
Send your part number, size list or drawing with quantity to DJF Seal for a quotation. We supply B2B, wholesale and OEM volumes with export packing.
