DKB Wiper Seal / Dust Seal (Black) | Factory Wholesale
DKB Wiper Seal / Dust Seal overview
DKB Wiper / Dust Seal (Black) is supplied by DJF Seal for hydraulic cylinders used in construction and industrial equipment. DJF is a direct hydraulic seal manufacturer and wholesale supplier, serving repair workshops, equipment dealers and OEM buyers worldwide. This listing groups the DKB Wiper / Dust Seal (Black) profile in its full available size range.
Key parameters
| Parameter | Value |
|---|---|
| Material | NBR + Iron |
| Performance | Temperature: -35°C to 100°C; |
| Application | These are most commonly used for the piston rods of hydraulic cylinders in excavators, loaders, cranes, forklifts, and agricultural machinery; the black DKB model is the preferred choice for wet and muddy operating conditions. |
Available sizes
The size(s) recorded for this profile. Dimensions in millimetres unless noted otherwise.
| Inner Diameter | Outer Diameter | Height | Slot Width |
|---|---|---|---|
| 13 | 19 | 4 | 5 |
| 14 | 22 | 4 | 7 |
| 14 | 24 | 5 | 7 |
| 18 | 30 | 6 | 9 |
| 19 | 26 | 5 | 7 |
| 19 | 27 | 4 | 7 |
| 19 | 31 | 6 | 9 |
| 19 | 32 | 6 | 9 |
| 20 | 28 | 4 | 6 |
| 20 | 30 | 4 | 6 |
| 20 | 32 | 6 | 9 |
| 22 | 32 | 6 | 9 |
| 22 | 31.1 | 6.5 | 8 |
| 22 | 34 | 6 | 9 |
| 25 | 37 | 6 | 9 |
| 28 | 40 | 6 | 9 |
| 30 | 42 | 6 | 9 |
| 30 | 47 | 7 | 10 |
| 32 | 39 | 5 | 9 |
| 32 | 44 | 7 | 10 |
| 32 | 52 | 8 | 11 |
| 35 | 47 | 7 | 10 |
| 38 | 50 | 7 | 10 |
| 40 | 52 | 7 | 10 |
| 40 | 62 | 8 | 11 |
| 45 | 57 | 7 | 10 |
| 45 | 68 | 7 | 10 |
| 50 | 62 | 7 | 10 |
| 50 | 64 | 8 | 11 |
| 50 | 72 | 8 | 11 |
| 55 | 69 | 8 | 11 |
| 60 | 74 | 8 | 11 |
| 60 | 82 | 11 | 15 |
| 63 | 77 | 8 | 11 |
| 65 | 79 | 8 | 11 |
| 66 | 80 | 8 | 10 |
| 68 | 90 | 10 | 14 |
| 70 | 84 | 8 | 11 |
| 70 | 90 | 10 | 14 |
| 75 | 89 | 8 | 11 |
| 80 | 94 | 8 | 11 |
| 80 | 95 | 6 | 7.5 |
| 85 | 99 | 8 | 11 |
| 90 | 104 | 8 | 11 |
| 95 | 109 | 8 | 11 |
| 100 | 114 | 8 | 11 |
| 105 | 121 | 9 | 12 |
| 110 | 126 | 9 | 12 |
| 115 | 131 | 9 | 12 |
| 120 | 136 | 9 | 12 |
| 125 | 141 | 9 | 12 |
| 130 | 146 | 9 | 12 |
| 135 | 155 | 10 | 14 |
| 140 | 160 | 10 | 14 |
| 145 | 165 | 10 | 14 |
| 150 | 170 | 10 | 14 |
| 160 | 180 | 12 | 14 |
| 170 | 190 | 12 | 14 |
| 175 | 195 | 12 | 17 |
| 180 | 200 | 10 | 14 |
| 180 | 205 | 12 | 17 |
| 185 | 210 | 12 | 17 |
| 190 | 215 | 12 | 17 |
| 200 | 216 | 9 | 12 |
| 200 | 225 | 12 | 17 |
| 210 | 230 | 12 | 17 |
| 220 | 245 | 12 | 17 |
| 240 | 265 | 12 | 17 |
| 250 | 275 | 12 | 17 |
| 260 | 285 | 12 | 17 |
Selection guide
To select the correct part, confirm the cylinder bore and rod diameter, the groove dimensions, the operating pressure and temperature, and the medium used. Check rod, housing, height and groove dimensions before ordering. Where a value is not stated above, confirm against drawing before ordering.
Request a quote
Send your part number, size list or drawing with quantity to DJF Seal for a quotation. We supply B2B, wholesale and OEM volumes with export packing.
